Spaltlampenmikroskop
Essential Ophthalmic Equipment for General Eye Clinic Examinations
- Led Light Source, Low Working Temperature,
- Long Service Life, Environmental Protection
- 14mm Light Spot, Large Field of View, Observing Entire Corniea and Iris
- Stepless Dimming Making Patients More Comfortable
- Upgrade to Digital Slit Lamp System
- Software Management of Patient Record
Slit Lamp Modelle
OVS-I
|
Microscope type |
Crossed Binocular microscope |
|
|
Objective Magnification |
Two Steps Magnifications | |
| Eye Piece |
10X |
|
|
Optic System |
Vergrößerungen |
10X, 16X |
|
Sichtfeld |
Φ22.5mm,Φ14mm | |
|
Diopter Adjustment |
-5D~+5D |
|
| Schülerabstand |
55mm~72mm |
OVS-II
| Microscope type | Galilean stereoscopic microscope |
| Objective Magnification | Five steps magnifications |
| Eye piece | 12.5X |
| Vergrößerungen | 6X，10X, 16X, 25X，40X |
| Diopter Adjustment | -5D~+5D |
| Schülerabstand | 55mm~72mm |
SL-350
Slit Width: 0-14mm Continuously Adjustable
Slit Height: 1-14 Stufenlos einstellbar
Aperture Size:0.2mm, 1mm, 3mm, 5mm, 10mm, 14mm, 1-14mm
Microscope Type: Galilean Parallel Angle
Magnification: 6.3X, 10X, 16X, 25X, 40X
Eyepiece Magnification: 12.5X
PD Adjustment: 54mm-87mm
Diopter Adjustment: ±7D
Filter: Heat Absorption, Grey, Red Free, Kobaltblau
SL-350A
Slit Width: 0-14mm Continuously Adjustable
Slit Height: 1-14 Stufenlos einstellbar
Aperture Size:0.2mm, 1mm, 3mm, 5mm, 10mm, 14mm, 1-14mm
Microscope Type: Galilean Parallel Angle
Magnification: 6.3X, 10X, 16X, 25X, 40X
Eyepiece Magnification: 12.5X
PD Adjustment: 52mm-85mm
Diopter Adjustment: ±8D
Filter: Heat Absorption, Grey, Red Free, Kobaltblau
SL-350AD
Canon EOS Digital Camera: 18 Mega Pixels
Slit Lamp Image Processing Software
Digital Slit Lamp Beam Splitter
Lifting Table
Slit Image (3)
Slit Lamp Anwendung
Slit lamp microscope is an essential instrument for ophthalmic examination. Slit-lamp microscope is composed of illumination system and binocular microscope, it can not only make superficial lesions very clear observation, but also can adjust the focus and light source width to make “optical section”, so that deep tissue lesions can also be clearly displayed.
A digital slit lamp microscope is a slit lamp Upgraded to digital imaging system, it contains digital camera and computer with software to manage the patients’ records.
As you know we have several models of slit lamp microscope, so please contact us to let us know which model you are interested in.
Normally for small order, we can ship out the products within 2 working days we receive your payment.
