Dental Microscope
Characteristics
- World Class Optical Quality
- Multi-function Knob
- Real Time Status Display
- One Finger Operation
- Digital and Smart Medical Treatment
Technical Data
|
Magnification System |
Manual Zoom System, with apochromatic 1:6 Ratio |
|
1.8X-20X with 12.5X Eyepieces |
|
|
Magnification Factor y=0.4X-2.4X |
|
|
11.6mm-124mm with 12.5X Eyepieces |
|
| Tubes |
0~180°Inclinable Binocular Tube with PD Adjusting Knob, f=170mm |
|
Eyepieces |
12.5X Wide-field Eyepieces, also Suitable for Eyeglass Wearers |
| Objective |
VarioDist Objective Lens, Variable Working Distance 200-450mm |
|
Illumination |
Integrated True Color LED Illumination |
|
Large Light Spot Diameter |
|
|
Yellow and Green Filters |
|
|
Mount Mobility |
Super Balancing Arm |
| Handgrip |
360°Rotatable Handgrip |
Main Features
Dental Microscope
Optical System
- Applying Germany Optical Lens
- Apochromatic Design
- Multilayer Optical Coating
- Ultrahigh Resolution
- Large Optical Depth of Field
- Relieve Eye Pressure
Dental Microscope
Multi Filters
- White LED: High Color Rendering Index Medical LED
- Yellow Filter: Prevent the Resin Material from Curing Too Fast
- Green Filter: To See the Tiny Blood Vessels in the Blood Environment
- Fluorescent Source: To Remove Diseased Tissue
